VTX Goes Low

Dual 18-inch subwoofer complements JBL’s flagship VTX A-Series loudspeakers, offering powerful bass with flexibility for any application

By

August 20, 2020

The VTX B28 is JBL Professional’s next-gen dual 18-inch subwoofer, designed to complement the company’s flagship VTX full-range sound reinforcement systems, and capable of delivering uncompromised low-frequency performance, even for the most demanding shows around. Differential Drive technology endows the drivers with exceptional performance, while SlipStream port technology offers improved airflow and reduced audible turbulence at any operating level.

The VTX B28 houses a new integrated rigging system that follows in the footsteps of the innovative and well-received A8 and A12 rigging designs, and allows the B28 to be suspended in omnidirectional or cardioid arrays of up to 16 enclosures. The rigging and a comprehensive collection of tour-tough accessories make the B28 a flexible solution for both mobile and installed sound system applications. The B28 integrates seamlessly with HiQNet Performance Manager and Line Array Calculator (LAC) software, and features the same industrial design as A- and B-Series loudspeakers, giving the entire system a cohesive look.

“The VTX B28 is our new premium subwoofer, and the ideal addition to VTX Series line array systems,” said HARMAN Professional Product Manager George Georgallis. “As with the B18 subwoofer, we started by taking the best aspects of the previous-generation S28 and G28 and improving performance. Then we optimised the design for a dual 18-inch system, and the result was the B28. We worked very hard to ensure the B28 could meet the most demanding applications, but also focused on configurability, a full suite of accessories, and software applications to make the B28 a solid investment and an outstanding performer for tour sound providers and rental companies.”

At the core of the B28 are two JBL Differential Drive 2288H-M 18-inch woofers, engineered for improved linearity, efficiency and extra-long excursion. The combination of the 2288H-M drivers and the large, central, flared port deliver superior low-frequency output without distortion or artifacts—even at elevated SPL. FEA-optimised integral bracing eliminates inter-cabinet standing waves, improves rigidity, and simplifies the structural design to create the lightest, yet strongest, possible product.

With versatile mounting and configuration options, the B28 fits seamlessly into any system. The streamlined, two-point rigging system uses integrated levers and locks, avoiding traditional quick release pins and retaining cables that can get damaged or lost, or limit the potential configurations. This enables the B28 to be stacked vertically or horizontally, using the independent sets of feet on the bottom and sides, while the spring-loaded design ensures there is no rattling during operation. Universal M20 mounts interface with supported VTX accessories for constructing complete ground stacked arrays. NL4 connectors on both the front and rear of the unit enable convenient wiring in standard or cardioid configurations.

CONTACT

JBL Professional: www.jblpro.com
Australian Distributor: www.cmi.com.au (touring) or madisonav.com.au (installed)
